Medical Sterilizing Dialyzing Paper Bag Packing Machine

Applications:
The machine is specially developed and manufactured by our scientific research personnel for packing four sides sealing Medical dressing, which is suitable for medical dressing, gauze swab and some platelet products packing,The machine drive by eight  sets servo motors and adopt PLC Programmable Controller to program operation of the whole machine. The main machine make up of servo driving, couple feeding parts, lot number printing parts, reciprocating heat sealing parts, horizontal and crossing cutting and the convey of finish products parts. The machine having vantage performance,easy maintenance and operation.

Main Feature:
△It adopts PLC programmable Controller and drive by servo motor to make running of the whole machine programmed.
△ The touch screen clearly displaying the speed, the length and width of the bag setting,
 the length of the bag automatic adjusting,and the packing length can directly setting, easy and quick
△Color code detecting,import photo electricity tracking the color code,making it correct
△ Automatic control temperature,the place of the heat sealing adopt couple temperature controller, improve the quality of the sealing

Technical Pharameter

Production Capacity	30-240bags/min(According with the Material）
The max film Roller size	φ400mm
Width of Packing Film	350mm
Packing Size	L70-450mm,W80-175mm,H1-5mm
Air compress	0.3m3/mi
Air pressure	0.5~0.7Mpa
Rated Voltage	AC380V  50Hz
Total Power	20KW           Heating Power 3.2KW
Weight	2750kg
Overall Dimension	5600*1730*1500
